Polycom SoundStation VTX1000 Specifications

Polycom SoundStation VTX 1000 Specifications
Part No. 3726-07633-001 Rev. 12/05
www.polycom.com
Polycom Headquarters: 4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
Polycom EMEA: 270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom Asia Pacific: Polycom Hong Kong Ltd., Rm 1101 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.2861.3113, (F)+852.2866.8028
Console
Size (L x W x H)
• 14.5 x 12.25 x 2.5 in
(36.8 x 31.1 x 6.4 cm)
Weight
• 1.75 lb. (0.8 kg)
Power
• 22VDC nominal; supplied by interface module
Display
• High-resolution backlit graphical LCD
Caller ID
• Bellcore type 1 (requires a telephone
company subscription for activation)
Keypad
• 12-key telephone keypad
• On-hook/off-hook, conference, mute, volume up/down
keys, menu, navigation keys
• 3 content-dependent soft keys including redial, hold
Console Loudspeaker
• Frequency response: 300 Hz to 3.3 kHz in narrowband
mode, 80 Hz to 7 kHz in wideband mode
• Volume: adjustable to 89 dB (peak) volume at 0.5 meters
Treble/Bass Controls
• Adjustment range: ± 6 dB
Console Microphones
• 3 cardioid microphones 80 Hz - 7 kHz
Console Interface
• RJ-45: proprietary P8 interface to interface module
• RJ-11: 32 Mbps serial link for future expansion
• 2 EX microphone connections
Sub-woofer
Size (L x W x H)
• 8.750 x 5.150 x 9.2125 in
(2.22 x 1.31 x 2.32 cm)
Weight
• 5.75 lb. (2.61 kg)
Miscellaneous
• Frequency response: 80 to 300 Hz in wideband mode
• Power: switchable 110/220 V, 50/60 Hz (100 V for Japan)
includes country-specific
AC cable
Interface module
Size
• 3.125 x 7.75 x 1.875 in
(7.9 x 19.7 x 4.8 cm)
Weight
• 0.75 lbs (0.34 kg)
Power
• 90 - 264 VAC, 50 - 60 Hz includes country-specific
AC cable
Auxiliary audio
Input
• Style: phono jack
• Function: switchable between Polycom wireless
mic/AUDIO IN/OFF
• Softkey configurable setup menus
Output
• Style: phono jack
• Function: switchable between subwoofer/external
PA/record out/OFF
• Softkey configurable setup menus
See user documentation for further specifications
Telco Interface
• Network connection: 2-wire RJ-11 analog PBX or
PSTN interface
• Speech mode
- Bandwidth 300 Hz to 3.3 kHz or 80 Hz to 7 kHz
(point-to-point)
• Network requirements: compatible with standard PSTN
and PBX networks, analog or G.711 encoded
• Software download mode
- Download protocol: V.34 compatible
- Connection rates: to 33 Kbps, depending on line quality
- Download server: Polycom download server
Extension Microphones
• 2 cardioid extension microphones (included), 80 Hz-7 kHz
Regulatory Compliance
• Safety
- UL 1950
- CSA C22.2, no. 950
- EN6-950
- IEC60950AS/NZS3260
• EMC
- FCC (47 CFR Part 15) Class B
- ICES-003 Class B
- EN55022 Class B
- CISPR 22 Class B
- AS/NZS 3548 Class B
- VCCI Class B
- EN50224
Environmental Requirements
• Operating temperature: 40º - 104ºF (5º - 40ºC)
• Relative humidity: 20% - 85% (noncondensing)
• Storage temperature: -22º - 131ºF (-30º - 55ºC)
Recommended Room Conditions
• Reverberation time: <0.54 seconds
• Noise level: <48 dBa
Warranty
• 12 months
Part Number
• 2200-07300-001 (Console only)
EX microphones and subwoofer purchased separately
SoundStation VTX 1000 Ships With:
• Tabletop console with integrated display and keypad
• Power/network interface module
• User documentation (user guide, quick installation guide,
registration card)
• Cables
- 1 Power cable (console)
- 1 21-ft. (6.4m) console cable
- 1 7-ft. (2.1m) telco cable
Audio Enhancements
• Automatic Gain Control (AGC)
• Dynamic Noise Reduction
• Gated microphones with intelligent microphone mixing
• 80 Hz to 7 kHz VTX wideband audio
©2005 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo, SoundStation, SoundStation Premier and Vortex are registered trademarks and VoiceStation, VSX, VTX, The Polycom Office,
Global Management System, SoundStation VTX 1000 and the industrial design of SoundStation are trademarks of Polycom, Inc. in the U.S. and various countries.
All other trademarks are the property of their respective companies. Specifications subject to change without notice.
Additional SoundStation VTX 1000 features/benefits
• Noise reduction technology automatically minimizes PC, projector, and HVAC sounds
• Automatic mic selection – only one mic is on at a time to remove “in the well” sound
• Independent microphone, echo-cancelled channels that optimize to their individual environment for better sound
• Extension mics provide even greater room coverage for larger rooms
• Subwoofer for audio extension down to 80 Hz, which provides clearer, lifelike sound
• Selectable, downloadable ring tones

Polycom SoundStation VTX1000 Specifications

Power

console power	22VDC nominal
subwoofer power	switchable 110/220 V, 50/60 Hz
interface module power	90 - 264 VAC, 50 - 60 Hz

Operating Environment

operating temperature	40º - 104ºF (5º - 40ºC)
relative humidity	20% - 85% (noncondensing)
storage temperature	-22º - 131ºF (-30º - 55ºC)

Weight and Dimensions

console size	14.5 x 12.25 x 2.5 in (36.8 x 31.1 x 6.4 cm)
console weight	1.75 lb (0.8 kg)
subwoofer size	8.750 x 5.150 x 9.2125 in (2.22 x 1.31 x 2.32 cm)
subwoofer weight	5.75 lb (2.61 kg)
interface module size	3.125 x 7.75 x 1.875 in (7.9 x 19.7 x 4.8 cm)
interface module weight	0.75 lbs (0.34 kg)
