14
5. Take out the Motor Assembly
p
.
6. Remove the Rubber Nozzle
o
. Be careful not to lose it.
PUMP DISASSEMBLY & STORAGE
1. Unplug the Pump from the power outlet.
2. For the Suction Fitting
2
: seal it with the SF Cap
5
.
For the Return Fitting
6
: remove the RF Diverter
7
, and seal it with the Service Plug
8
.
3. Vent the Pump by slowly loosening the Vent Screw
e
.
4. Loosen all four Hose Clamps
q
, detach both the Hoses
9
, and drain any remaining water.
5. Clean and dry all parts, including the Cartridge.
6. Liberally lubricate the Vent Screw O-Ring
r
and Gasket Top
y
with petroleum jelly. Then reassemble them with the Vent Screw, Seal Top and Canister.
7. Put all the parts into an airtight plastic bag, and store in a dry place that remains above 32°F (0°C) at all times.
PUMP SERVICING INSTRUCTIONS
19
17
21
19
17
The most efficient way to troubleshoot or replace the Pump is to remove the entire Pump Motor Assembly
p
. The Motor is consisted of a Rotor Assembly
f
and
its related parts. If any of its parts is/are broken, or if it is not seated in place between the Volute Cover
g
and the Pump Body
d
, the Rotor will not function
properly even in perfect condition.
STEP 1: Removal of the Motor
1. Unplug the Pump from the power outlet.
For the Suction Fitting
2
: seal it with the SF Cap
5
.
For the Return Fitting
6
: remove the RF Diverter
7
, and seal it with the Service Plug
8
.
2. Vent the Pump by slowly loosening the Vent Screw
e
.
3. Detach the Hose Clamps
q
and Hoses
9
attaching to the Pump inlet and outlet.
4. Turn the Pump upside down, and remove the Canister Screws
s
.
19
18
To Next Page
