Polygroup RX330 User Manual

OWNER’S MANUAL
7
PARTS LIST
1. READ ALL INSTRUCTIONS CAREFULLY and get a thorough understanding of what is required to assemble your Filter Pump.
2. It is recommended to have some petroleum jelly (not included) on hand for lubricating the gaskets and o-rings.
IMPORTANT:
1. The installer shall follow the written instructions provided for the operation of the filter pump system.
2. All electrical components shall be installed in accordance with Article 680 of the 2017 National Electrical Code
®
(NEC
®
) or its latest approved edition.
3. This Filter Pump is manufactured by Polygroup
®
and ETL control number 4000608 and 4006317 – double insulated and grounded – 120VAC 60Hz. All units must
have a minimum of 105VAC to start and run properly.
Model
RX330
Wattage
30 Watts
Amperage
0.5 Amps
FILTER PUMP POWER INFO
ItemQty.Parts Name
Fitting Gasket (black)
Suction Fitting (SF)
SF Washer
Fitting Lock Nut
SF Cap
Return Fitting (RF)
RF Diverter
RF Service Plug
Hose
Hose Clamp
Filter Pump Assembly
Vent Screw
Vent Screw O-Ring
Seal Top
Gasket Top
Canister Gasket / Motor Seal
Pump Canister
Rubber Nozzle
Pump Motor Assembly
Type I Filter Cartridge
Canister Screw
Pump Body
Rotor Assembly
Volute Cover
Volute Cover Screw
GFCI Power Cord Set
1.25” O-Ring (for hose connection)
1
1
1
1
1
1
6
1
1
1
2
1
4
2
1
1
2
1
1
1
1
2
4
1
1
1
1
Qty.Parts Name
Item
1
2
3
4
5
6
7
8
9
21
15
16
17
18
19
20
22
23
24
25
26
27
10
11
12
13
14
PRELIMINARY STEPS

Polygroup RX330 Specifications

General

Brand	Polygroup
Model	RX330
Category	Water Filtration Systems
Language	English
