Sensor 2: Secondary parameter
OUT. 1: DL Min.
value
Used to set the minimum value of output 1
OUT. 1: DL Max.
value
Used to set the maximum value of output 1
OUT. 1: DL gain
mA/s
Used to set the "responsiveness" of the 4-20 mA output. Possible value: 0 to
40 mA/s
If Active Function : Test fixed value
OUT.1 : TEST Value
mA
Possibility of simulation a value between 4.0 and 20.0 mA by step of 0.1
mA
If Active Function : PID Controler
OUT.1 : PID Type
Used to set output 1 to operate within a range of 0-20 mA or 4-20 mA
OUT.1 : PID linked
param.
Used to select the parameter whose value shall be outputted for the PID
function :
Sens.1.pri.meas
Sens.1.sec.meas
Sens.2.pri.meas
Sens.2.sec.meas
OUT.1 : PID % Band
Configurable between 0.00 and 1000.00
Proportional to the gap between the measure and the instruction
OUT.1 : PID Integral
Choice between Active (by fault) and Inactive
if OUT.1 : PID Integral: Active
OUT.1 : PID Integral
Customizable between 0.00 and 1000.00 s
OUT.1: PID
Derivative
Choice between Inactive (by fault) and Active
If OUT.1 : PID Derivative : Active
OUT.1: PID
Derivative
Customizable between 0.00 and 1000.00 / s
OUT.1: PID gain
Used to set the "responsiveness" of the 4-20 mA output. Possible value: 0 to
40 mA/s
OUT.1: PID Direction
Configurable in Direct or Reversed Mode
Configuration of the Analog Output 2
OUT2 :Active
function
Configuration of the output 2 according to 4 choices:
No function
Recorder
Test – Fixed Value
PID Controler
If Active Function : Recorder
OUT. 2: Active
Function
This function activates analog output 2.
Used to set output 2 to Data logger mode (for when the output is connected
to a controller/data logger).
OUT. 2: DL type
Used to set output 2 to operate within a range of 0-20 mA or 4-20 mA.
OUT. 2: Parameter
linked to DL
Used to select the parameter whose value shall be outputted via analog
output 2:
