Sensor 1: Primary parameter
Sensor 1: Secondary parameter
Sensor 2: Primary parameter
Sensor 2: Secondary parameter
OUT. 2: DL Min.
value
Used to set the minimum value of output 2
OUT. 2: DL Max.
value
Used to set the maximum value of output 2
OUT. 2: DL gain
mA/s
Used to set the "responsiveness" of the 4-20 mA output. Possible value: 0 to
40 mA/s
If Active Function : Test fixed value
OUT.2 : TEST Value
mA
Possibility of simulation a value between 4.0 and 20.0 mA by step of 0.1
mA
If Active Function : PID Controler
OUT.2 : PID Type
Used to set output 2 to operate within a range of 0-20 mA or 4-20 mA
OUT.2 : PID linked
param.
Used to select the parameter whose value shall be outputted for the PID
function :
Sens.1.pri.meas
Sens.1.sec.meas
Sens.2.pri.meas
Sens.2.sec.meas
OUT.2 : PID % Band
Configurable between 0.00 and 1000.00
OUT.2 : PID Integral
Choice between Inactive and Active
if OUT.2 : PID Integral: Active
OUT.2 : PID Integral
Customizable between 0.00 and 1000.00 s
OUT.2: PID
Derivative
Choice between Inactive and Active
If OUT.2 : PID Derivative : Active
OUT.2: PID
Derivative
Customizable between 0.00 and 1000.00 / s
OUT.2: PID gain
Used to set the "responsiveness" of the 4-20 mA output. Possible value: 0 to
40 mA/s
OUT.2: PID Direction
Configurable in Direct or Reversed Mode
Maintenance Mode is activated under the following conditions:
- When a calibration is being performed,
- If communication with the sensor(s) is lost,
- If the measurement delivered by the sensor is incorrect,
- If an On/Off input in Washing Mode is activated.
