Upper/overrange: when a limit is exceeded by being overshot
Lower/underrange: when a limit is exceeded by being undershot
Interval: the range is set by a combination of upper and lower limits.
If Active function: Limit Indicator and Type of Limit (Upper/overrange or Lower/underrange)
Used to set the value of the Upper or Lower limit
Possible values: 0 to 20 %
Possible values: 0 to 3600 s
If Active function: Limit Indicator and Type of Interval limit
Used to set the value of the UPPER limit
Possible values: 0 to 20 %
Possible values: 0 to 3600 s
Minimum time during which the contact (CLOSED or OPEN) shall be
maintained in that state (between 0 and 120 minutes)
Used to set the value of the LOWER limit
Possible values: 0 to 20 %
Possible values: 0 to 3600 s
Minimum time during which the contact (CLOSED or OPEN) shall be
maintained in that state (between 0 and 120 minutes)
Used to set output 1 to one of the following:
Not assigned
Fault alarm
Limit indicator
If Active function: Fault alarm
Relay can be set to Open or Closed mode
A time delay which must elapse prior to the triggering of the relay. Possible
values: 0 to 3600 s
If Active function: Limit indicator
Relay can be set to Open or Closed mode
Used to select the parameter linked to output 2:
Sensor 1: Primary parameter
Sensor 1: Secondary parameter
Sensor 2: Primary parameter
Sensor 2: Secondary parameter
Used to define the limit triggering mode:
Upper/overrange: when a limit is exceeded by being overshot
Lower/underrange: when a limit is exceeded by being undershot
Interval: the range is set by a combination of upper and lower limits.
