If Active function: Limit Indicator and Type of Limit (Upper/overrange or Lower/underrange)
R2: Limit Value
Used to set the value of the Upper or Lower limit
R2: Hysteresis limit
%
Possible values: 0 to 20 %
R2: Tempo
Possible values: 0 to 3600 s
If Active function: Limit Indicator and Type of Interval limit
R2: UPPER limit
value
Used to set the value of the UPPER limit
R2: Hysteresis limit
%
Possible values: 0 to 20 %
R2: Tempo
Possible values: 0 to 3600 s
R2: Forcing Tempo
Minimum time during which the contact (CLOSED or OPEN) shall be
maintained in that state (between 0 and 120 minutes)
R2: LOWER limit
value
Used to set the value of the LOWER limit
R2: Hysteresis limit
%
Possible values: 0 to 20 %
R2: Tempo
Possible values: 0 to 3600 s
R2: Forcing Tempo
Minimum time during which the contact (CLOSED or OPEN) shall be
maintained in that state (between 0 and 120 minutes)
Maintenance Mode is activated under the following conditions:
- When a calibration is being performed,
- If communication with the sensor(s) is lost,
- If the measurement delivered by the sensor is incorrect,
- If an On/Off input in Washing Mode is activated.
The conditions under which an On/Off input is activated in "Fault alarm" mode are:
- No response from sensor x parameter x,
- Poor response from sensor x parameter x,
- Out-of-range measurement for sensor x parameter x,
- Measurement not possible for sensor x parameter x,
- Low sensor power supply voltage,
- Low internal battery voltage,
- High internal temperature,
- Poor sensor communication response,
- On/Off input 1 alert
- Analysis of Actéon5000 program
- Low limit exceeded for analog input 1 or Upper limit exceeded for analog input 1
- On/Off input 2 alert
- Low limit exceeded for analog input 2 or Upper limit exceeded for analog input 2
