Pool Technologie Poolsquad - Measuring Chamber

AUTOSALT®/POOLSQUAD®/POOLSQUAD® AMPERO/PRO - PAPI004082 – FR/EN/ES/DE - Rev.03.16
8
For the Poolsquad ® Ampéro and Pro Model in addition
MEASURING CHAMBER
1/ Position the 2 saddles
2/ After having to apply Teflon on the spigot, Screw gates of isolation on the saddle
3/ After having to apply Teflon on the spigot, screw injection connector on the gates of isolation.
4/ Connect a part of the tubing between injection connector and measuring
8
Flow sensor in option
Poolsquad® Pro
Poolsquad® Ampéro
Poolsquad® Pro
