6. REPAIRS
In the event of a problem, the heat pump’s screen displays an error code instead of temperature
indications. Please consult the table below to nd the possible causes of a fault and the actions to
be taken.
6.1 Breakdowns and faults
WARNING: Under normal conditions, a suitable heat pump can heat the water in
a swimming pool by 1°C to 2°C per day. It is therefore quite normal to not feel any
temperature di󰀨erence in the system when the heat pump is working.
A heated pool must be covered to avoid any loss of heat.
Code Fault Name Action
E03 AC current protection Shutdown protection
E04 AC voltage protection Shutdown protection
E05 DC voltage protection Shutdown protection
E06 Phase current protection Shutdown protection
E07 High IPM temp. protection Shutdown protection
E09 High exhaust temp. protection Shutdown protection
E14 Low outlet water temp. protection Shutdown protection
E15 High coil temp. protection (cooling) Shutdown protection
E16 High outlet water temp. protection (heating) Shutdown protection
E17 Flow switch fault Shutdown protection
E18 High pressure switch fault Shutdown protection
E19 Low pressure switch fault (pass, shut down after 30s) Shutdown protection
E22 Inlet and outlet temp. di󰀨erence too high protection Shutdown protection
E23 Low ambient temp. protection(heating) Shutdown protection
E24 Low ambient temp. protection(cooling) Shutdown protection
E25 Low inside coil temp. protection(cooling) Shutdown protection
E26 DC Fan fault(No feedback speed) Shutdown protection
E49 Inlet sensor fault Use outlet water replace logical judgment
E50 Coil sensor fault Cancel the corresponding logical judgment
E51 Discharge sensor fault Shutdown protection
E52 Suction sensor fault Cancel the corresponding logical judgment
E53 Inside coil sensor fault(cooling) Use outlet water replace logical judgment
E54 Ambient sensor fault Cancel the corresponding logical judgment
E57 Outlet sensor fault Cancel the corresponding logical judgment
D17 Driver IPM over current protection System 1 shutdown
D18 Driver 1 compressor drive fault(except IPM ) System 1 shutdown
D19 Driver 1 compressor over current protection System 1 shutdown
D22 Driver IPM over temp. protection System 1 shutdown
D23 Driver PFC fault System 1 shutdown
D24 Driver 1 DC bus over voltage protection System 1 shutdown
D25 Driver 1 DC bus under voltage protection System 1 shutdown
D26 Driver 1AC under voltage protection System 1 shutdown
D27 Driver 1 AC over current protection System 1 shutdown
D33 Driver 1 IPM temp. protection System 1 shutdown
D34 Drive 1 DC fan 1 fault System 1 shutdown
D36 Driver 1 transformer output 15V under voltage protection System 1 shutdown
Code Fault Name
P1 Water inlet sensor error
P3 Coil temp. sensor error
P5 Ambient temp.sensor error
P7 Low temp. protection
E7 Water ow protection
E6 Low pressure error
Defrosting indicator (Green
light)
Defrosting
