1 - ENG
PIN138
PIN NAILER
Cloueuse de goupilles
Clavadora
www.deltaportercable.com
INSTRUCTIVO DE OPERACIÓN, CENTROS
DE SERVICIO Y PÓLIZA DE GARANTÍA.
LÉASE ESTE INSTRUCTIVO
ANTES DE USAR EL PRODUCTO.
Française : Page 15
Español: Página 30
Instruction manual
Manuel d'instructions
Manual de'instrucciones

Table of Contents

Questions and Answers

  • C
    Christopher GutierrezAug 13, 2025
    Why does my Porter-Cable Nail Gun jam frequently?
    • M
      Mrs. Kelly CombsAug 13, 2025
      Your Porter-Cable Nail Gun might be jamming due to several reasons: you may be using incorrect or damaged fasteners, or the fasteners might be loaded incorrectly. Check if the fasteners are approved and of the correct size. Fastener fragments might be jammed in the nosepiece. Also, the magazine or nose screws might be loose, or the magazine could be dirty. In this case, tighten the screws and clean the magazine. A worn or damaged driver tip can also cause jams, and it may need replacement with Driver Maintenance Part # 60118.
  • C
    Cheryl MoraAug 17, 2025
    Why is there an air leak near the top or in the trigger area of my Porter-Cable Nail Gun?
    • Y
      yeseniapatrickAug 17, 2025
      An air leak near the top of your Porter-Cable Nail Gun or in the trigger area is likely due to loose screws or worn/damaged o-rings or seals. Try tightening the screws first. If that doesn't solve the problem, install Overhaul Kit (Part # 60117) to replace the worn or damaged o-rings or seals.
  • C
    Catherine RyanAug 20, 2025
    Why is there an air leak near the bottom of my Porter-Cable PIN138?
    • C
      Carla LeonAug 20, 2025
      If you notice an air leak near the bottom of your Porter-Cable Nail Gun, it could be due to loose screws, or worn or damaged o-rings and bumper. Try tightening the screws. If the leak persists, consider installing Overhaul Kit (Part # 60117) to replace the worn components.
  • M
    Miss Marissa GrantAug 25, 2025
    Why does my Porter-Cable PIN138 jam so frequently?
    • J
      Joshua HardingAug 25, 2025
      Your Porter-Cable Nail Gun might be jamming frequently due to several reasons. It could be that you are not using approved fasteners of the correct size. There might be fastener fragments jammed in the nosepiece. The fasteners could be loaded incorrectly, or they might be damaged. The magazine or nose screws could be loose, or the magazine might be dirty. Finally, the driver tip could be worn or damaged. To resolve this, verify that you are using approved fasteners of the correct size. Also, make sure to clean the magazine, and tighten any loose magazine or nose screws. If the driver tip is worn or damaged, consider installing Driver Maintenance Kit (Part # 60118). If fasteners are loaded incorrectly or damaged, see 'To Load Tool' and replace damaged fasteners.
  • K
    Katherine SanchezAug 28, 2025
    How to fix an air leak near the top of my Porter-Cable PIN138 Nail Gun or in the trigger area?
    • C
      crystalmeltonAug 28, 2025
      An air leak near the top of your Porter-Cable Nail Gun or in the trigger area is likely caused by worn or damaged o-rings or seals. To fix this, install Overhaul Kit (Part # 60117).
  • Z
    zachary42Aug 31, 2025
    What causes an air leak near the bottom of a Porter-Cable PIN138 Nail Gun?
    • D
      dustin25Aug 31, 2025
      An air leak near the bottom of your Porter-Cable Nail Gun is likely caused by worn or damaged o-rings or a bumper. To resolve this, install Overhaul Kit (Part # 60117).
  • P
    Paul RamirezSep 4, 2025
    What to do if my Porter-Cable PIN138 does nothing or operates sluggishly?
    • D
      David JimenezSep 4, 2025
      If your Porter-Cable Nail Gun isn't working or seems sluggish, the causes could be: an inadequate air supply, worn or damaged o-rings or seals, or a fastener jammed in the nosepiece. First, verify that the air supply is adequate. If the air supply is sufficient, consider installing Overhaul Kit (Part # 60117) to address potential issues with o-rings or seals. If a fastener is jammed, refer to the section on clearing a jammed nail.
  • T
    Travis RoseSep 8, 2025
    How to fix loose screws on my Porter-Cable PIN138?
    • H
      Heidi EdwardsSep 9, 2025
      If you have loose screws on your Porter-Cable Nail Gun, simply tighten them.

Summary

Important Safety Instructions for Pneumatic Tools

Save These Instructions

Eye and Hearing Protection Requirements

Operator and others must wear safety glasses and hearing protection.

Air Supply Quality and Pressure Regulation

Use clean, dry air and regulate pressure compatible with tool ratings.

General Safety Precautions

Compressed Gas and Coupling Safety Warnings

Avoid bottled gases and use pressure-relieving couplings.

Disconnecting and Storage Procedures

Loading Fasteners Safely

Connect tool to air supply before loading, avoid trigger activation.

Trigger Safety and Pre-Use Inspection

Inspect trigger for proper function; do not tamper with tool.

Handling and Work Area Precautions

Operational Safety Guidelines

Maintaining Balance and Footing

Intended Use and Material Limitations

Nosepiece Safety and Fastener Placement

Workpiece Securing and Body Clearance

Flammable Environments and Recoil Safety

Additional Safety and Health Precautions

Actuation Against Workpiece

Depth Adjustment Safety

Blind Nailing Hazard

Operator Alertness and Dust Hazards

Mandatory Safety Equipment

Always use certified safety glasses, hearing, and respiratory protection.

Air Fitting and Operation Preparation

Preparing the Tool for Use

Nailer Operation Procedures

Loading the Nailer

Step-by-step guide on how to load fasteners into the magazine.

Actuating the Nailer

How to fire fasteners using the trigger and safety trigger.

Depth Adjustment and Jam Clearing

Adjusting Driving Depth

How air pressure controls fastener depth and how to adjust it.

Clearing a Jammed Nail

Procedure to safely remove jammed fasteners from the nosepiece.

Maintenance and Service Information

Maintenance and Cleaning Procedures

Troubleshooting and Tool Specifications

Troubleshooting Guide

Lists common problems, their causes, and solutions.

Porter-Cable PIN138 Specifications

General IconGeneral
TypePneumatic
Fastener TypeBrad Nails
Fastener Gauge18
Operating Pressure70-120 PSI
Depth AdjustmentYes
No-Mar TipYes
Tool-Free Jam ReleaseYes
Magazine Capacity100
Length9.5 in
