Wall Mount Kit Installation
4-4.
Secure the wall plate to the wall by 1.
fastening screws (x4).
The Wall Mount Kit includes a wall plate, a metal bracket, and one screw. (refer
to Chapter 1-2 item e) Please follow the steps below for installation.
2. Attach the metal bracket to the
back side of the sytem by fastening
the screw (x1) as picture shown.
3. Align the large end of
the teardrop mounting
holes (x4) on the wall
plate with the screws
(x4) on the systems
rear cover. Slide the
wall plate until the
screws are even with
the narrow end.
