POS-X EVO-TP4 - Connectors & Functions

19
Connector Purpose
CN1 Power Button Connector
CN3 Printer Port Reset
CN4 Printer Port
CN5/8 HDD Power
CN11 COM5 For Touch
CN13 Card Reader Connector
CN14 Line out
CN15 HDD LED
CN16 Speaker & MIC
CN18 MIC IN
CN20/JP10 System Indicator
CN22 USB Port
CN23 PS2 KEYBOARD
CN26 LVDS
CN27 Inverter Connector
CN29 System Fan
DDR3_A1 DDR3 SO-DIMM1
DDR3_A2 DDR3 SO-DIMM2
PRN1 Parallel Port
PWR1 +19V DC Jack
RJ11_1 Cash Drawer Connector
RJ45_1 COM1, COM2, COM3, COM4
RJ45_2 LAN
SATA1 SATA Connector
SATA2 SATA Connector
USB1 USB1, USB2
USB2 USB3, USB4
SW1 Power Button
JP1 CMOS Operation Mode
JP3/6 VGA Port
JP4/5 COM2 RS232/485/422 Setting
JP8 LCD ID Setting
JP9 Power Mode Setting
JP12 System Reset
JP14 Inverter Selection
JP18 COM3/4 Power Setting
JP19 Cash Drawer Power Setting
