POS-X EVO-TP4 - Connectors & Functions

26
Connector Purpose
BAT1 CMOS Battery Base ( Use CR2023)
CN1 Power On Button
CN3 Power LED
CN4 SATA1 HDD Power Connector
CN5 SATA2 HDD Power Connector
CN6 LCD Interface Connector
CN8 For External Touch Connector
CN9 Inverter Connector
CN10 Card Reader Connector
CN12 LED
CN14 Speaker & MIC Connector
CN15 CD-IN Connector
CN18 USB5
CN20 PS2 KEYBOARD
DDR2_A1 DDR2 SO-DIMM1
DDR2_A2 DDR2 SO-DIMM2
SATA1 SATA Connector
SATA2 SATA Connector
SW1 Power On Button
JP1 CRT Connector
JP3 Power Option for COM3/COM4
JP4 2nd Display Power
JP5 COM2 Connector
JP6 COM2 RS232/422/485 Setting
JP7 LCD ID Setting
JP9 AT Function
JP11 Cash Drawer Power Setting
JP12 Hardware Reset
6-2-2.
Connectors & Functions
