KeepSafe Essential
23
MOUNTING
Wall Mounting
There are four (4) wall mounting bracket options to choose from: 8208
Wall Bracket, 8208CS Command Strip Alarm Mounting System, 8208G
GCX Alarm Mounting Bracket Assembly, and the 8208H Modular
Services Alarm Mounting Bracket Assembly.
8208 WALL BRACKET
1. Choose a location out of the patient’s/
resident’s reach, but with indicator
lights in clear view of staff.
2. Use Wall Bracket (Cat. 8208) (Fig. 15).
3. Screw Attachment:
•
Position wall bracket with back (flat
side) against wall (Fig. 15).
•
Using bracket as a guide, mark spots
to insert anchors into wall.
Make sure it is safe to drill and there
are no pipes or electrical wires that
could be damaged.
•
Drill holes where marked and insert
anchors.
•
Position bracket over holes. Insert
and tighten screws.
4. Slide alarm onto bracket from top
down until it is firmly in place.
5. To remove alarm, gently push release
lever IN while sliding alarm up and out
(Fig. 16).Make sure magnet and/or
AC adapter cable can be secured
out of the way and do not present a
tripping hazard.
Fig. 16 - Alarm/Bracket
(Front View)
PRESS LEVER
SLIDE OUT
HOLD/SUSPEND
SLIDE
ALARM UP
RELEASE
LEVER
Fig. 15 - 8208 Chair/Wall
Bracket (Front View)
PRESS LEVER
SLIDE OUT
RELEASE
LEVER
SCREW
HOLES
