PULSERPLUS PRO™ HIGH RESISTANCE GROUNDING SYSTEM
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
4750 Olympic Blvd. • Erlanger, KY 41018 • USA
Phone: 800-537-6144 / 859-283-0778 • Fax: 859-283-2978
www.postglover.com
Serving the Electrical Industry Since 1892
PGR Document #HG111-06© 2006 Post Glover Resistors, Inc.
PULSERPLUS PRO™ HIGH RESISTANCE GROUNDING SYSTEM
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
© 2006 Post Glover Resistors, Inc. 10
Release the SYSTEM TEST pushbutton. Press and hold the ALARM SILENCE pushbutton and the audible alarm
should cease. Press the RESET pushbutton and the red and green lights and auxiliary contacts should revert to
their normal states.
Without Test Resistor
This test will verify operation of the PulserPlus Pro™ module only. The test bypasses the neutral grounding
resistorandmostofthecircuitrybyopeningtheneutralgroundingcircuitandapplyingcontrolvoltage(~120Vac)
to the PulserPlus Pro™ controller module.
Enter a value lower than 100 volts in the Fundamental Voltage Hi Limit Setpoint.
The same procedure that is used with a test resistor can now be followed.
