PULSERPLUS PRO™ HIGH RESISTANCE GROUNDING SYSTEM
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
4750 Olympic Blvd. • Erlanger, KY 41018 • USA
Phone: 800-537-6144 / 859-283-0778 • Fax: 859-283-2978
www.postglover.com
Serving the Electrical Industry Since 1892
PGR Document #HG111-06© 2006 Post Glover Resistors, Inc.
PULSERPLUS PRO™ HIGH RESISTANCE GROUNDING SYSTEM
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
4750 Olympic Blvd. • Erlanger, KY 41018 • USA
Phone: 800-537-6144 / 859-283-0778 • Fax: 859-283-2978
www.postglover.com
Serving the Electrical Industry Since 1892
© 2006 Post Glover Resistors, Inc. 17
The Lo Limit setpoint indicates the level at which the Loss of Ground condition will activate. For a Harmonic Lo
Limit, it may also indicate a Ground Fault.
Using the UP ARROW and DOWN ARROW buttons, the voltage lo limits may be set to any voltage between 0
and 400 volts. For Medium Voltage applications, see the schematic prints provided with the unit for information on
setting this value. The amperage lo limits may be adjusted between 00.0 and 16.0 amps. A setting of 0A disables
the amperage lo limit feature.
6.8 Pulsing Timer
The Pulse Rate used to locate ground faults can be adjusted from 0.5 to 3.0 seconds in increments of 0.1
seconds. The setpoint indicates time on and time off, so a setting of 1.0 S results in the pulse on for 1 second and
offfor1second(pulserateof30perminute).
Calculation:60/[2*setpoint(seconds)]=pulserateperminute
Sample Settings 0.5 s 1.0 s 2.0 s 3.0 s
Resulting Pulse Rate 60 / min 30 / min 15 / min 10 / min
6.9 Alarm Delay
The Alarm Delay setpoints indicate the amount of time between a fault indication and the alarm activation in
seconds. During the alarm delay time, the system will monitor the fundamental and/or harmonic voltage and/or
amperage measurement. If the faulted parameter returns to a value within the set limits prior to the expiration of
the delay, the alarm will be canceled. Thus, a transient high measurement will not activate the alarm. The default
setting for this setpoint is 4.5 seconds.
Using the UP ARROW and DOWN ARROW buttons, the alarm delay may be set for any time between 0 and 20.4
seconds.
6.10 Auto Reset
WhenturnedOn(enabled),auto-resetwillresettheunitwhenafaultiscleared.
WhenturnedOff(disabled),ausermustpresstheALARMSILENCEandRESETbuttonstoplacethesystemin
NORMAL state after clearing a fault.
Setpoint 0.6 S
Pulse Time Set
Setpoint 04.5 S
Fnd Alarm Delay
Setpoint 04.5 S
Hrm Alarm Delay
Auto Reset On
(Off/On)
