PULSERPLUS PRO™ HIGH RESISTANCE GROUNDING SYSTEM
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
4750 Olympic Blvd. • Erlanger, KY 41018 • USA
Phone: 800-537-6144 / 859-283-0778 • Fax: 859-283-2978
www.postglover.com
Serving the Electrical Industry Since 1892
PGR Document #HG111-06© 2006 Post Glover Resistors, Inc.
PULSERPLUS PRO™ HIGH RESISTANCE GROUNDING SYSTEM
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
© 2006 Post Glover Resistors, Inc. 8
3.6 Line and Control Connections
RefertoapplicationspecicdrawingsthataccompanythePostGloversystem.Generally,thelineconnections
are made from either the top or bottom of the enclosure. Space is provided for line cables to run down the side
without any cable bends. The control power and auxiliary device connections are made to the terminal blocks
rated 30 amperes, 600 volts.
Refertothespecicdiagramsfurnishedwiththeequipmentforlocationdetail.
Asanalcheck,inspectallwiringtoverifythatconnectionsaremadeproperlyandthattheyarecleanandtight.
Make sure there is adequate clearance between the external connections and all devices.
3.7 Setting Resistor Tap Connections
Adjust the resistor at installation so that ground current with one ground fault is equal to or greater than the
system capacitive-charging current. As long as this minimum criteria is met, the exact magnitude of the setting is
not critical. In fact, a value slightly higher than the system capacitive-charging current may be selected to allow for
futuresystemgrowth.Amethodformeasuringthecapacitive-chargingcurrent(Ic)isdescribedinSection5ofthis
instruction manual. Refer to the elementary schematics for grounding resistor connections.
3.8 General
When the installation is complete and all incoming wiring has been terminated, clean the inside of the unit with
a soft cloth or vacuum cleaner. Make sure any dirt or debris, such as packing material, is removed so it does not
interfere with the operation of the unit. Before connecting power to the control panel, check all components to
make sure all shipping devices, such as blocking or tying of relays, have been removed.
