Power Electronics Standalone NB 120 User Manual

NB 120
POWER ELECTRONICS
18
INTRODUCTION
Connectors
The charger has up to two independent cable straight hoses with the standard connectors. The
possibility of installing and combining the connectors depends on which regulations are applied in each
country and the interest in offering different options to the users.
The connector brackets are located on each side of the equipment.
The following sections describe the parts of each type of connector. Be aware that the shape of the
connectors may vary from those listed below.
CCS-1 connector
CCS-2 connector
CHAdeMO connector
Locking system
Handle grip
Handle grip
Locking system
Handle grip
Locking system
