When installing the equipment, keep the minimum safety distances. Be aware of all the minimum
insulation requirements established by the applicable electrical code, as well as the thermal,
safety and accessibility requirements. The safety distances given in this section must not replace
in any way the mandatory regulations of the country in which the equipment will be installed.
For proper inspection and ventilation, as well as correct handling, it is important to leave clearance
around the equipment. The following image shows the recommended minimum distances:
Side to side distance:
Front side distance: It does not require a special front space, beyond the one that allows a user to
access the display and the RFID.
Although this is the minimum distance between chargers, the distance between parking spaces to be
able to maneuver between two cars must also be taken into account, as well as the maximum range of
the hose.
Rear side distance: It does not require a special rear space; it can be installed in touch with a wall or
other element.
