PREPARATION FOR INSTALLING THE EQUIPMENT
Ventilation system
Special care must be taken to ensure that there are no external elements near the air inlets and
outlets that prevent proper ventilation of the equipment.
The equipment has a forced ventilation system with an inlet located on the right side of the equipment
(front view) and a hot air outlet on the opposite side.
CAUTION
Hot air outlet
Cold air inlet
