TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS
Depending on the regulation to be followed, the equipment will fulfill different technical characteristics.
Standalone NB 120 – IEC
REFERENCE
NB0600H
NB060SH
NB0900H
NB090SH
NB1200H
NB120SH
DC OUTPUT
Maximum power [kW]
60
90
120
Voltage range [V]
150 – 1000
[1]
Available connectors
CCS-2, CHAdeMO
Maximum continuous current CCS
[A]
200 (optionally, 250 or 300)
Peak current CCS [A]
[2]
350
Maximum current CHAdeMO [A]
125
Maximum number of EVs charging
simultaneously
1
1
2
AC OUTPUT
(OPTION)
Power [kW]
22
Voltage range [V]
400 ± 10%
Maximum current [A]
32
Available connectors
AC Type 2 Socket
AC INPUT FOR
DC OUTPUT
Power [kVA]
63
95
126
Voltage [V]
400 (3ph + N + PE) ± 10%
Power factor
> 0.99
Frequency [Hz]
50 / 60
Efficiency
95%
GENERAL
Interface
10" Touchscreen
RFID card reader
Emergency stop pushbutton
Credit / debit card reader (optional)
Protections
Isolation monitor
Surge arrester Type 2 (optional)
DC charge: RCD Type A (optional) + MCB
AC charge (optional): MCB + RCD Type A + RCM
Others
Smart Fleet Management
Smart Power Balance (optional)
Meter
DC meter for DC output (optional)
AC MID meter for AC output
Cable length [m]
5 with cable management system (optionally, 7.6)
Enclosure / foot / glass color
White (RAL 9016) / Grey (RAL 7016) / Black
Customization
[3]
Enclosure / Foot / Glass / Logo / Display
Degree of protection
IP54 | IK10 (IK08 for display and ventilation grilles)
Operating temperature
From -30°C to 50°C
Relative humidity
From 4% to 95%
Maximum altitude (above sea
level)
≤ 2000 m without derating (max. 3000 m)
Communications
Ethernet + OCPP 1.6 + Wifi + 3G / 4G connectivity
Dimensions (W x D x H) [mm]
670 x 750 x 1800
Regulation
IEC 61851-1, IEC 61851-23, IEC 61851-24, IEC 61851-21-2:2018
Notes: [1] 150 - 500 Vdc for CHAdeMO.
[2] Consult with Power Electronics for more information about the connector overload capability.
[3] Consult with Power Electronics for further information.
Be aware that Power Electronics is not responsible for the charger's input power connection, as well as its
installation.
