POWER ELECTRONICS
NB 120
DIMENSIONS AND WEIGHT
25
The front and left view, from left to right, are shown below:
GRAVITY CENTER
X
Y
Z
mm
864
371
412
in.
34.02
14.60
16.22
The approximate weight for the NB 120 is 360 kg (793.66 lb)
1
.
1
For other equipment of the NB 120 range, consult Power Electronics.
