22
Model
PM-0800LC
PM-0800SLU
PM-1600LC
PM-1600SLU
PM-2400LC
PM-2400SLU
Capacity VA / Watt
1.2KVA /
800W
2.4KVA /
1600W
3.6KVA /
2400W
Battery Voltage 12Vdc 24Vdc 24Vdc
Backup Time (at full load) * long time available
Battery
Max. Charging Current
(5 steps selectable) *
> 40A > 50A
Solar Inverter status, I/P&O/P Voltage
Frequency, Load%,
Display LCD
LCD
Battery Voltage & %, Charge current *,
Temperature, Model
LED Normal (Green), Warning (Yellow), Fault (Red)
Battery Mode Beeping every 4 seconds
Low Battery Beeping every second
Inverter Fault Beeping Continuously
Audible Alarm
Overload Beeping twice per second
Operation Temperature 0-40 degree C; 32-104 degree F
Relative Humidity 0-95% non-dondensing
Environment
Audible Noise Less than 55dBA (at 1M)
Net Weigh (Kgs) 12.00 24.00 31.50
(WxHxD)mm Rack Mount 440*132*290 440*132*360 440*132*360
Physical
(WxHxD)mm Wall Mounted 298*400*150 298*450*190 298*450*190
* Feature on SLU models only.
Specifications are subjected to change without prior notice.
23
Model
PM-4000LC
PM-4000SLU
PM-6000LC
PM-6000SLU
PM-8000LC
PM-8000SLU
Capacity VA / Watt
5KVA /
4000W
6KVA /
6000W
8KVA /
8000W
Nominal Voltage 220Vac ; 110Vac 220Vac only
Acceptable Voltage
Range
120-275Vac ; 60-135Vac 120-275Vac
Frequency 50Hz / 60Hz ( 45Hz - 70Hz)
Line Low Transfer 120VAC ± 2% ; 60VAC ± 2% 120VAC ± 2%
Line Low Return 130VAC ± 2% ; 65VAC ± 2% 130VAC ± 2%
Line High Transfer 275VAC ± 2% ; 135VAC ± 2% 275VAC ± 2%
Input
Voltage
Range
Line High Return 260VAC ± 2% ; 130VAC ± 2% 260VAC ± 2%
Voltage
220Vac (230V or 240VAC re-settable via LCD
panel);
110Vac (115V or 120VAC re-settable via LCD
panel)
Voltage Regulation
(Batt. Mode)
< 3% RMS for entire battery voltage range
Frequency 50Hz or 60Hz
Frequency Regulation
(Batt. Mode)
±0.1Hz
Power Factor 0.8 1.0
Waveform Pure Sine Wave
Efficiency > 80%
Line Mode Circuit Breaker
Output
Overload
Protection
Battery Mode 110% ~ 150% for 30 sec., > 150% for 200 ms
Transfer Time Typical * < 8 ms.
To Next Page
