Powerhouse PH4000Ri/E - Technical Specifications

PH4000Ri/E Owner’s Manual41
10. Specications
Generator
Model PH4000Ri/E
Rated frequency (Hz) 60
Rated voltage (V) 120
Rated current (A) 30 A
Max current (A) 33.3 A
Rated output (W) 3600 W
Max output (W) 4000 W
DC Output 12 V, 8.3 A
Phase Single
Battery 12 V
Battery fuse 20 Amp, ATC style
Engine
Model XG-177F
Type 4 stroke, 1-cylinder, air-cooled, OHV, gasoline engine
Horsepower/Displacement 6.8/270cc
Compression ratio 9.2:1
Engine speed 3600 RPM +/- 100 RPM
Ignition system Computer-controlled
Spark plug F7RTC
Starting system Remote, Electric, & Recoil
Fuel Automotive unleaded gasoline
Lube oil (synthetic or conventional) SAE 10W-30/15W-30 (0W-30/0W-40 below 32°F)
Oil Capacity 33.8  oz (1.0 L)
Fuel tank capacity 4.5 gal (17.0 L)
Continuous running time at (rated output) 8.9 hours
Continuous running time at (¼ load) 18 hours
Continuous running time at (½ load) 14.5 hours
Noise level (no load - full load) dB@ 23’ (7m) 64 – 74 dB
Tune Up Specications
Spark Plug Gap 0.028 - 0.031 in (0.7 - 0.8 mm)
Valve Clearance (Intake) 0.0031 - 0.0039 in (0.08 - 0.10 mm)
Valve Clearance (Exhaust) 0.004-0.006 in (0.10 - 0.15 mm)
Dimensions
Overall dimension H×W×D in (mm) 23.25" x 23" x 25.8" (591 x 584 x 655mm)
Dry weight, with battery 146.8 lbs (66.6kg)
