PH4000Ri/E Owner’s Manual 8
2. Using the handles
• Using the telescoping handles to move the generator without locking them properly can make
movement unstable, leading to injury or generator damage.
This generator includes a total of four (4) handles. Two of the handles are embedded into the top of the cabinet on the
ends (one handle over the control panel and one handle over the mufer grill). These handles are appropriate for rolling
the generator along even, smooth terrain, or for tie-down during transportation. There are also two telescoping handles
that make moving the generator along rough or uneven terrain easier. The handles extend outward parallel with the top
of the unit and lock in place so that the generator may be moved, wheelbarrow-style, with stability. When not in use, the
handles slide into the interior of the generator, locked in place by rotating them clock-wise until tight.
• For safety reasons, it is better to shut the generator down before moving it. You should also unplug
all cords connected to the generator to prevent a tripping hazard and/or damage to the cords or
receptacles.
• Ensure that the telescoping handles are properly stowed and locked when they are not being used to
move the generator.
• The handles tighten in place when locked. They should not wobble or otherwise move.
To extend and lock the telescoping handles:
1. Rotate each rubber grip counter-clockwise to unlock the handles.
2. Pull the handles outward from the body of the generator until they are fully extended.
3. Rotate each grip clockwise to lock the handles in place.
To unlock the extended handles and stow them properly:
1. Rotate each rubber grip counter-clockwise to unlock the handles.
2. Slide the handles into the body of the generator until they are fully seated.
3. Rotate each grip clockwise to lock the handles in place.
WARNING
!
CAUTION
!
NOTE
!
Embedded Handle
Telescoping
handle
Telescoping
handle
Embedded Handle
Handle stowed
and locked
Locking rotation
Unlocking rotation
