K Series User Guide
456 mm / 18 in
(K2/K3: 338 mm / 13.3 in)
466 mm / 18.3 in
(K2/K3: 348 mm / 13.7 in)
497 mm / 19.6 in
(K2/K3: 380 mm / 15 in)
25 mm / 1 in
44.5 mm / 1.7 in
440 mm / 17.3 in
465 mm / 18.3 in
483 mm / 19 in
16 mm
/ 0.6 in
6 mm
/ 0.2 in
6.25 mm / 0.2 in
32 mm / 1.26 in
8 mm / 0.3 in
FIGURE 85: K Series dimensions
