PowerTech MP3768 User Manual

23
OPERATION:
Parameters Default Range Operation Steps
SYS* 12VDC 12/24 VDC
1. Under the " USE " interface, press the ENTER
button to enter the “SYS” interface.
2. Press the ENTER button again to display the
current “SYS” value.
3. Press the SELECT button to modify the
parameter.
4. Press the ENTER button to confirm and enter
the next parameter.
BCV 14.4V 9~17V
5. Press the ENTER button again to display the
current voltage value.
6. Press the SELECT button to modify the
parameter (short press to increase 0.1V, long
press to decrease 0.1V).
7. Press the ENTER button to confirm and enter
the next parameter.
FCV 13.8V 9~17V
LVR 12.6V 9~17V
LVD 11.1V 9~17V
LEN NO YES/NO
Press the SELECT button to modify the switch
status. NOTE: It exists automatically from the
current interface after no operation of more than
10S.
*The SYS value can only be modified under the non-lithium "USE" type. That is, the battery type is
Sealed, Gel, or Flooded before entering the "USE" type, the SYS value can be modified; if it is lithium
battery type before entering the "USE" type, the SYS value cannot be modified.
Only the above battery parameters can be set on the local controller, and the remaining battery
parameters follow the following logic (the voltage level of 12V system is 1, the voltage level of 24V
system is 2).
Voltage control
parameters
Sealed/Gel/Flooded
User
LiFePO4 User Li(NiCoMn)O2 User
Over voltage
disconnect voltage
BCV+1.4V*
voltage level
BCV+0.3V*
voltage level
BCV+0.3V*
voltage level
Charging limit voltage
BCV+0.6V*
voltage level
BCV+0.1V*
voltage level
BCV+0.1V*
voltage level
Over voltage
reconnect voltage
BCV+0.6V*
voltage level
BCV+0.1V*
voltage level
Boost charging
voltage
Equalize charging
voltage
BCV+0.2V*
voltage level
Boost charging
voltage
Boost charging
voltage
Boost reconnect
charging voltage
FCV-0.6V*
voltage level
FCV-0.6V*
voltage level
FCV-0.1V*
voltage level
Under voltage
warning reconnect
voltage
UVW+0.2V*
voltage level
UVW+0.2V*
voltage level
UVW+1.7V*
voltage level
Under voltage
warning voltage
LVD+0.9V*
voltage level
LVD+0.9V*
voltage level
LVD+1.2V*
voltage level
Discharging limit
voltage
LVD-0.5V*
voltage level
LVD-0.1V*
voltage level
LVD-0.1V*
voltage level
