PowerTech MP3768 User Manual

26
• The following rules must be observed when modifying the
parameter values in User for a lithium battery.
A. Over Voltage Disconnect Voltage > Over Charging Protection
Voltage(Protection Circuit Modules(BMS))+0.2V;
B. Over Voltage Disconnect Voltage > Over Voltage Reconnect Voltage =
Charging Limit Voltage ≥ Equalize Charging Voltage = Boost Charging
Voltage ≥ Float Charging Voltage > Boost Reconnect Charging Voltage;
C. Low Voltage Reconnect Voltage > Low Voltage Disconnect Voltage ≥
Discharging Limit Voltage.
D. Under Voltage Warning Reconnect Voltage > Under Voltage Warning
Voltage ≥ Discharging Limit Voltage;
E. Boost Reconnect Charging voltage > Low Voltage Reconnect Voltage;
F. Low Voltage Disconnect Voltage ≥ Over Discharging Protection Voltage
(BMS)+0.2V
WARNING
• The voltage parameters of a lithium battery can be set
according to the lithium battery BMS's voltage parameters.
• The required accuracy of BMS shall be no higher than
0.2V. We will not assume any responsibility for the system
abnormal when the accuracy of BMS is higher than 0.2 v.
Local load mode Setting
When the LCD shows the above interface, operate as follows:
Operation:
1. Press the "SELECT" button to jump to the load type interface.
2. Press and hold the "ENTER" button until the load type interface flashes.
3. Press the "SELECT" button to modify the load type.
4. Press the "ENTER" button to confirm.
OPERATION:
