PQR Series Model D52
Page 38
www.Powertronics.com
V2.1
C6 - (Option 4) Set the Surge, Sag, and Power Fail:
This Command allows the operator to change the threshold points for the PQR D50/52 events.
Select Option 4: 4
The PQR D50/52 will respond by transmitting the following message
To set a fixed threshold, type the desired number of the setting:
To set the Temperature Surge setting to 98 degrees, type 98 at
Temp channel - Surge Threshold.... : (5%, 10%).. : 98
followed by a carriage return.
The PQR D50/52 will respond (98), indicating that it will now trip at 98 degrees.
Note:
These settings are saved in Non-Volatile FLASH RAM, and are used as the power up default.
AC channel - Surge Threshold....... : (5%, 10%).. :
AC channel - Sag Threshold........... : (5%, 10%).. :
AC channel - Power Failure............ : (5%, 10%).. :
DC Channel - Surge Threshold.......... : (5%, 10%).. :
DC Channel - Sag Threshold.............. : (5%, 10%).. :
DC Channel - Power Failure.............. : (5%, 10%).. :
Temp channel - Surge Threshold....... : (5%, 10%).. :
