Powerware 5115 - Page 26

Installation
20
Powerware
®
5115 Tower UPS (500–1400 VA) U ser’s Guide S 05146640 Rev C www.powerware.com
Network Transient
Protector
Two 5-15 Receptacles
Four 5-15 Receptacles
6-ft Power Cord
with 5-15 Plug
Fan
Communication Port
DIP Switches
Site Wiring Fault
Indicator
USB Port
Input Overcurrent
Protector
Figure 5. 1000 VA, 120V Rear Panel
Six 5-15 Receptacles
6-ft Power Cord
with 5-15 Plug
Network Transient
Protector
Fan
Communication Port
DIP Switches
Site Wiring Fault
Indicator
USB Port
Input Overcurrent
Protector
Figure 6. 1400 VA, 120V Rear Panel
