Installation
21
Powerware
®
5115 Tower UPS (500–1400 VA) U ser’s Guide S 05146640 Rev C www.powerware.com
Communication Port
Four 10A, IEC-320
Receptacles
DIP Switches
Network Transient
Protector
10A, IEC-320
Input Connector
USB Port
Figure 7. 500 VA, 230V Rear Panel
Four 10A, IEC-320
Receptacles
DIP Switches
Network Transient
Protector
10A, IEC-320
Input Connector
Fan
Communication Port
USB Port
Figure 8. 750 VA, 230V Rear Panel
