Installation
22
Powerware
®
5115 Tower UPS (500–1400 VA) U ser’s Guide S 05146640 Rev C www.powerware.com
Two 10A, IEC-320
Receptacles
Four 10A, IEC-320
Receptacles
10A, IEC-320
Input Connector
Fan
DIP Switches
Network Transient
Protector
Communication Port
USB Port
Figure 9. 1000 VA, 230V Rear Panel
Six 10A, IEC -320
Receptacles
Fan
10A, IEC-320
Input
Connector
DIP Switches
Network Transient
Protector
Communication Port
USB Port
Figure 10. 1400 VA, 230V Rear Panel
