UPS Maintenance
80
Powerware
®
9155 UPS (8–15 kVA) User’s Guide S 164201553 Rev D www.powerware.com
Figure 42 shows a UPS with a separate battery cabinet and a
UPS-mounted bypass switch.
UPS-Mounted Bypass Switch
Bypass
Service
Bypass
Service
UPS
UPS
UPS
User-supplied
Bypass
Service
Building
Service
Panel
Load
Distribution
Panel
UPS EBM
Figure 42. Typical Hardwired Installation with UPS-Mounted Bypass Switch
