Chapter 10 Communication
This section describes the:
쑺 DB -9 communication port
쑺 X-Slot cards
쑺 LanSafe Power Management Software
쑺 Remote Emergency Power-off
쑺 Relay output contacts
쑺 Programmable signal inputs
Figure 32 shows the location of the communication options and control
terminals on the UPS.
DB-9 Communication Port
REPO (Normally Closed)
REPO (Normally Open)
Signal Input 2
Signal Input 1
X-Slot Communication Bay #2
X-Slot Communication Bay #1
Relay Contact
Figure 32. Communication Options and Control Terminals
