Section V. Function parameter table
DC bus voltage 4
Output voltage 5
Actual motor rotating speed
6
Accumulated running time
7
IGBT temperature 8
*reserved 9
*reserved 10
Motor output power 11
*reserved 12~15
F67
V/F curve set
F68
MSS speed control
F69
I/O group select
F70
CUR group select
F71
SPD group select
F72
PID group select
F73
SYS group select
F74
MOT group select
Press
[PROG/ENT]
- Y
5-2. Other Parameters
5-2-1. F67 V/F curve [V/F]
Ref
LCD keyboard
explanation
Range of set value Unit
setting
Y/N
0.00~U02 F03=0
5.00
U00
V/F set fre 1
0.0~U02 F03=1
Hz
50.0
N
U01
V/F set voltage 1
0~U03 %
5 N
F03=0
10.00
U02
V/F set fre. 2 U00~U04
F03=1
Hz
100.0
N
U03
V/F set voltage 2
U01~U05 %
10 N
F03=0
15.00
U04
V/F set fre. 3 U02~U06
F03=1
Hz
150.0
N
U05
V/F set voltage 3
U03~U07 %
15 N
F03=0
20.00
U06
V/F set fre. 4 U04~U08
F03=1
Hz
200.0
N
U07
V/F set voltage 4
U05~U09 %
20 N
U08
V/F set fre. 5 U06~U10
F03=0
Hz
25.00
N
Section V. Function parameter table
F03=1
250.0
U09
V/F set voltage 5
U07~ U11 %
25 N
F03=0
30.00
U10
V/F set fre. 6 U08~U12
F03=1
Hz
300.0
N
U11
V/F set voltage 6
U09~U13 %
30 N
F03=0
35.00
U12
V/F set fre. 7 U10~U14
F03=1
Hz
350.0
N
U13
V/F set voltage 7
U11~U15 %
35 N
F03=0
40.00
U14
V/F set fre. 8 U12~F13
F03=1
Hz
400.0
N
U15
V/F set voltage 8
U13~100 %
40 N
5-2-2. F68 MSS group [MSS]
Ref
LCD keyboard
explanation
Range of set value Unit
setting
Y/N
F03=0
5.00
H00
1 step speed 1X
F16~F17
F03=1
Hz
50.0
Y
F03=0
30.00
H01
2 step speed 2X
F16~F17
F03=1
Hz
300.0
Y
F03=0
20.00
H02
3 step speed 3X
F16~F17
F03=1
Hz
200.0
Y
F03=0
30.00
H03
4 step speed 4X
F16~F17
F03=1
Hz
300.0
Y
F03=0
40.00
H04
5 step speed 5X
F16~F17
F03=1
Hz
400.0
Y
F03=0
45.00
H05
6 step speed 6X
F16~F17
F03=1
Hz
450.0
Y
F03=0
50.00
H06
7 step speed 7X
F16~F17
F03=1
Hz
500.0
Y
H07
1 step time T1 0.0~3200.0 s 2.0 Y
H08
2 step time T2 0.0~3200.0 s 2.0 Y
H09
3 step time T3 0.0~3200.0 s 2.0 Y
H10
4 step time T4 0.0~3200.0 s 2.0 Y
H11
5 step time T5 0.0~3200.0 s 2.0 Y
H12
6 step time T6 0.0~3200.0 s 2.0 Y
