PR electronics 4116 - Graphic: Latch Function Setpoint Behavior; Latch Setpoint Timing and Release Conditions

30 4116V105-UK
Relay latched
OFF delay
ON delay
Input
signal
Hysteresis
Setpoint
(increasing)
Time
Closed
Open
Relay contact
(N.O.)
Release not possible (setpoint still exceeded)
Release not possible (setpoint-hysteresis still exceeded)
Release not possible (OFF delay still exceeded)
Release possible (manual deactivation)
Graphic depiction of latch function setpoint
