9113 TEMPERATURE / mA CONVERTER Safety Manual
Name Function
Ni.TYPE Ni sensor type (for SENSOR = Ni):
50 = Ni50
100 = Ni100
120 = Ni120
1000 = Ni1000
TC.TYPE Thermocouple type (for SENSOR = TC):
TC.B = Thermocuple type B
TC.E = Thermocuple type E
TC.J = Thermocuple type J
TC.K = Thermocuple type K
TC.L = Thermocuple type L
TC.N = Thermocuple type N
TC.R = Thermocuple type R
TC.S = Thermocuple type S
TC.T = Thermocuple type T
TC.U = Thermocuple type U
TC.W3 = Thermocuple type W3
TC.W5 = Thermocuple type W5
TC.Lr = Thermocuple type Lr
CJC CJC type for SENSOR = TC:
INT = Internal CJC sensor measurement
CONN = CJC connector measurement (accessory)
O.RANGE Fixed output range for current output:
0-20 = 0...20 mA Not valid when EN.SIL = YES (Safety applications)
4-20 = 4...20 mA
20-0 = 20...0 mA Not valid when EN.SIL = YES (Safety applications)
20-4 = 20...4 mA
