PR 9113 - Product Information and Specifications; Electrical Specifications

9113 - Product Version 9113-004 9
Electrical specifications
Environmental conditions
Specifications range ............................................... -20...+60°C
Storage temperature .............................................. -20...+85°C
Calibration temperature ........................................ 20...28°C
Relative humidity..................................................... < 95% RH (non-cond.)
Protection degree .................................................... IP20
Installation in ............................................................. Pollution degree 2 & measurement /
overvoltage category II
Mechanical specifications:
Dimensions (HxWxD) .............................................. 109 x 23.5 x 104 mm
Dimensions (HxWxD) w/ 4501 / 4511 ........... 109 x 23.5 x 116 / 131 mm
Weight approx. .......................................................... 250 g
Weight incl. 4501 / 4511 (approx.) .................. 265 g / 350 g
DIN rail type ............................................................... DIN EN 60715 / 35 mm
Wire size ...................................................................... 0.13...2.08 mm
2
AWG 26...14
stranded wire
Screw terminal torque ........................................... 0.5 Nm
Vibration ...................................................................... IEC 60068-2-6 : 2007
Vibration: 2...13.2 Hz .............................................. ±1 mm
Vibration: 13.2...100 Hz ........................................ ±0.7 g
Common specifications:
Supply voltage, DC .................................................. 19.2...31.2 VDC
Max. consumption .................................................... ≤ 3.5 W (2 channels)
4501 = Display / programming front
4511 = Communication enabler
5910Ex = CJC connector, channel 1
5913Ex = CJC connector, channel 2
9400 = Power rail
9404 = Module stop for rail
9410 = Power control unit
9420 = Power supply 24 V / 120 W - Ex nAC
Ordering codes for 9113
Type Channels
9113 Single : A
Double : B
Accessories
