PR 9113 - Technical Data and Accuracy; Isolation and Signal Parameters; Accuracy Specifications

10 9113 - Product Version 9113-004
Fuse ............................................................................... 400 mA SB / 250 VAC
Isolation - test / working:
Input to any ...................................................... 2.6 kVAC / 300 VAC reinforced
Analogue output to supply ........................ 2.6 kVAC / 300 VAC reinforced
Status relay to supply .................................. 1.5 kVAC / 150 VAC reinforced
Communications interface ................................... Communication enabler 4511 /
Programming front 4501
Signal / noise ratio .................................................. Min. 60 dB (0...100 kHz)
Average response time incl. delay:
Temperature input ......................................... ≤ 1 s
mA input ............................................................ ≤ 0.4 s
Accuracy, the greater of the general and basic values:
Basic values
Input
type
Basic
accuracy
Temperature
coefficient
mA ≤ ±16 µA ≤ ±1.6 µA / °C
Pt100, Pt200,
Pt 1000 ≤ ±0.2°C ≤ ±0.02°C / °C
Pt500, Ni100,
Ni120, Ni 1000 ≤ ±0.3°C ≤ ±0.03°C / °C
Pt50, Pt400, Ni50 ≤ ±0.4°C ≤ ±0.04°C / °C
Pt250, Pt300 ≤ ±0.6°C ≤ ±0.06°C / °C
Pt20 ≤ ±0.8°C ≤ ±0.08°C / °C
Pt10 ≤ ±1.4°C ≤ ±0.14°C / °C
TC type:
E,J,K,L,N,T,U ≤ ±1°C ≤ ±0.1°C / °C
TC type: R, S, W3,
W5, LR ≤ ±2°C ≤ ±0.2°C / °C
TC type: B
160...400°C ≤ ±4.5°C ≤ ±0.45°C / °C
TC type: B
400...1820°C ≤ ±2°C ≤ ±0.2°C / °C
General values
Input
type
Absolute
accuracy
Temperature
coefficient
All ≤ ±0.1% of span ≤ ±0.01% of span / °C
