PR 9113 - Input Signal Details; RTD Input Specifications; TC Input Specifications

9113 - Product Version 9113-004 11
EMC immunity influence .................................................. < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ................................. < ±1% of span
RTD input:
Input for RTD types:
Pt10*, Pt20*, Pt50*, Pt100, Pt200, Pt250, Pt300, Pt400, Pt500, Pt1000
Ni50, Ni100, Ni120, Ni1000
Cable resistance per wire (max.) ....................... 50 Ω
Sensor current ........................................................... Nom. 0.2 mA
Effect of sensor cable resistance
(3- / 4-wire) ................................................................ < 0.002 Ω / Ω
Sensor error detection ........................................... Programmable ON / OFF
Sensor error current:
when detecting ............................................... < 2 μA
else......................................................... 0 μA
* No short circuit detection for Pt10, Pt20 and Pt50
TC input:
Input
type
Min.
value
Max.
value Standard
Pt100
Ni100
-200°C
-60°C
+850°C
+250°C
IEC60751
DIN 43760
Type
Min.
value
Max.
value Standard
B
E
J
K
L
N
R
S
T
U
W3
W5
LR
+0°C
-100°C
-100°C
-180°C
-200°C
-180°C
-50°C
-50°C
-200°C
-200°C
0°C
0°C
-200°C
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
+2300°C
+2300°C
+800°C
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
ASTM E988-90
ASTM E988-90
GOST 3044-84
