PRECITEC CHRocodile C - Sensor Characteristics; Sensor Unit Characteristics

22
2.8 Sensor Characteristics
2.8.1 Sensor unit characteristics
Optical sensor
Measuring principle
(1)
Confocal Chromatic
Measuring data
(1)
Distance, Thickness
(1)
Light source
LED
Dimensions (sensor unit)
99.3 x 65 x 47 mm (L x W x H)
(2)
Weight
425g
Data Transmission
Measurements / second
Up to 4000 Hz
Interfaces
Ethernet, RS422, external analogue converter box as accessory
Transfer rate
Ethernet (100Mbits); RS422 (9600 – 921600 Baud)
Synchronization with ext. devices
Trigger-input / Output (TTL)
Encoder-inputs
Optional: 2 encoders input available through analogue converter box accessory
SDK
DLL written in C, C++ / SDK written in C# with .NET framework 4
OS
Windows XP, Windows 7, Windows 8
Data processing / calculation
Embedded processing unit
Standard to be met
Supply voltage
24V
DC
+/-10% with separate main supply unit 100 to 240VAC – 50Hz to 60Hz
Rated power
4W
Operating temperature
0 °C to +50 °C
Storage temperature
-20°C to +70°C
CE marking / EMC
Compliant with applicable regulation
RoHS
Compliant with applicable regulation
Protection class
IP50 (DIN 40050/ IEC 144)
Metrological specifications
Axial resolution / Repeatability
(3) (4)
3x10
-5
x Measuring Range
Accuracy
(4)
2x10
-4
x Measuring Range
Optical probes specifications
See Table 2.7
Order number
5009276
Table 2.6: Sensor Characteristics
(1) See section 2-3: Sensor functionalities. With CHRocodile C, the transmitted data are limited to up to 4 Altitudes, up to
4 Intensities and up to 3 Thicknesses.
(2) See Fig A2-2 Sensor unit mechanical plan in Appendix 2 CHRocodile C unit mechanical plan.
