PRECITEC CHRocodile C - Software and Communication Methods; Explorer Installation and Communication Options; Communication via Explorer, DLL, and ASCII

31
3.3.2 Via CHRocodile C DLL:
DLL is used to interface the sensor with a general-purpose user program. This CHRocodile C DLL is
written in C, C++ language and is intended for .NET compatible language. This DLL allows to use
whole CHRocodile C functionalities. In order to obtain further detailed refer to CHRocodile C DLL
documentation.
A CD containing the DLL, some code examples and the operating Manual is delivered with the
CHRocodile C.
3.3.3 ASCII command communication
The ASCII commands can be sent to the controller via the RS422 interface using a specific command
structure described on Appendix 1.
Serial interface communication can be used to configure the sensor and receive measurement data.
As an example, the Windows™ « Hyper Terminal »™ utility can be used to send the commands and
configure the sensor via the RS232 or RS422 communication port.
