Peak Signal:
Definition: Bit 8 = 1 (Bit 8 and 14 = 1)
Type:
For geometrical quantities like thickness or distance
Integer 16bit, scaled as fraction of measurement range, without refractive index (optical thickness) Distance and thickness values are given as:
d[µm] = value * $SCA[µm] / 32768.
In order to get the geometrical thickness, the value has to be multiplied by the index of refraction of the material.
For non-geometrical quantities (like intensity)
Truncated 16bit integer value
Statistics are not supported by CLS. Statistics are supported by CLS
explorer. Consequently the respective bit 11 to 13 are set to 0.
Corresponding to .NET function:
sodx.AltitudePeakSignalOffset1 = eSodxPeakSignalOffset.Average;
See Following Example
