Assembling the AMT 41
5. Using the ⁹₁₆-inch open-ended wrench, move the jam
nuts upward until they contact the side arm supports.
Tighten the jam nuts completely.
6. Align the rear pedestal over the back frame tube and the
side arm covers, then press it gently into place.
Figure 24: Rear pedestal attachment
