Precor Discovery Series User Manual

Seated Dip Assembly Guide: Getting Started 3
Hardware Kit (not to scale)
The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.
Table 1. Hardware kit contents
Fasteners Quantity
Buttonhead cap screw (³₈-inch x 38 mm)
1
Buttonhead cap screw (M12 x 16 mm)
4
Buttonhead cap screw (M8 x 70 mm) 2
Buttonhead cap screw (M8 x 15 mm) 1
Buttonhead cap screw (M5 x 25 mm)
10
Socket head cap screw (M12 x 35 mm)
14
Socket head cap screw (M10 x 30 mm) 4
