You will need assistance to assemble this unit. DO
NOT attempt assembly by yourself.
Follow these installation requirements when assembling the unit:
Assemble the unit near the place where you plan to use it.
Locate the equipment at least 40 inches (1 meter) away from walls or
furniture on either side of the equipment, and 40 inches (1 meter) away
from objects behind the equipment.
Set up the unit on a solid, flat surface, so that it remains level and stable. A
level unit has fewer malfunctions.
Open the box and assemble the components in the sequence presented in
this guide.
Insert, align, and thread all fasteners with your fingers. This helps prevent
cross-threading. Do not wrench tighten fasteners until instructed to do so.
Important: Before you wrench tighten a fastener, check that its head is flush
with the surface of the product. If not, cross-threading may have occurred. Do
not attempt to rework the assembly as more damage to the equipment will
occur. Instead, contact Customer Support as described in Obtaining Service.
If you plan to move the unit, get help and use a hand truck.
Required Tools
Torque wrench that can be fitted with the following hex bits:
⁷₃₂-inch hex bit
⁵₁₆-inch hex bit
⁵₃₂-inch hex bit
Socket wrench that can be fitted with the following sockets:
⁹₁₆-inch socket
1-inch socket
³₄-inch socket
³₄-inch open-end wrench
⁵₃₂-inch hex wrench
Torque screwdriver fitted with a #2 Phillips bit
Getting Started
