PRESONUS FIRESTATION - Stand-Alone Mode (With DigiDesign 001)

7
2.8 Stand-Alone Mode (With DigiDesign 001™)
Created,
Designed and
Manufactured
In The USA
POWER
LINE OUTPUTS - TRS BALANCED
1 3 5 7
2 4 6 8
ADAT™
optical
IN
OUT
LINE INPUTS - TRS BALANCED
1 3 5 7
2 4 6 8
PREAMP
SEND - TRS
1
2
MAIN OUT
L
R
FOOTSWITCH
(Record Punch)
CLOCK
MIDI - S/PDIF
(S/PDIF input and output
on channels 7/8)
FIREWIRE PORTS
PreSonus
FIRESTATION
115/230 VAC ~
By internal Jumper
30Watts
COMPUTER
DIGIDESIGN 001™
NOTE: You would want to be in ADAT special mode for this application.
