70
8 Resources
8.4 Technical Specications
StudioLive
™
ARc Series
Owner’s Manual
SD Recorder
Supported Media Format FAT16-formatted SD Card, FAT32-formatted SDHC Card
Media Storage Capacity SD Card: 2 GB, SDHC Card: 32 GB
Recording File Format Stereo WAV
Playback File Formats Stereo WAV, MP3
Sampling Rate (WAV) 44.1 kHz
Bit Depth Recording: 24-bit,
Playback: 16- and 24-bit
Power
Connector IEC
Input Voltage Range 90 to 240 VAC
Physical AR16c AR12c AR8c
Length 15.6” (397 mm) 15.6” (397 mm) 12.3” (313 mm)
Width (chassis only) 18.9” (480 mm) 15” (381 mm) 11” (284 mm)
Maximum Height 3.5” (89 mm) 3.5” (89 mm) 3.5” (89mm)
Weight 14.1 lbs (6.4 kg) 11.9 lbs (5.4 kg) 7.1 lbs (3.2 kg)
Global Warming
Recommended Ambient Operating Temperature 0˚ to 40˚ Celsius / 32˚ to 104˚ Fahrenheit
