664Y3300
Item Code Description
10800018 Room thermostat ACV 22
1x 1x
10800095
Module AM3-11:
Manages the second heating circuit -
communicates directly with the MCBA
1x 1x
537D3040
Contact sensor, 12kΩ
For outlet on controlled circuit.
1x 1x
10510900
Contact thermostat RAM 5109:
Obligatory to protect all floor heating circuits.
1x 1x
10510100
Outside temperature sensor, 12kΩ — AF120
1x 1x
10800104
2 circuit manifold DN32:
With built-in wall mounts.
1x
10800105
3 circuit manifold DN32:
With built-in wall mounts.
1x
10800107
High temperature kit DN32:
Includes: a circulator, two isolation valves,
the check valve and two thermometers.
1x 2x
10800106
Low temperature kit DN32:
Includes: a circulator, two isolation valves,
the check valve,
two thermometers, a 3-way valve with built-in
bypass.
1x 1x
10800142
Manifold connection kit DN32
Includes: two stainless steel hoses Ø 6/4"
with two reducers Ø 5/4"
1x 1x
10800019
Servomotor SQK 349:
Motor for valve provided in the low-temperature kit
(opening time: 150 seconds)
1x 1x
5476G003
Sensor NTC 12kΩ:
Monitors the external domestic hot water tank.
1x
