128-9316
3 of 16
Page 3
14 Pin Main Wiring Harness Part # 1124303
6 Pin Power Harness Part #1124297
3 Pin Door Lock Output Harness Part #1122906
1 Black/White (-) Horn Output
2 LT. Green (-) Additional Negative Trigger Input
3 NC Empty Cavity
4 Brown (-) Negative Door Trigger Input
5 DK. Green (-) Negative Trigger Input Hood & TNK
6 Purple (+) Positive Door Trigger Input
7 Orange/White (-) Ground Out When Disarmed
8 Yellow Ignition Input (12 VDC On & Start)
9 White/Blue (-) Output For Headlight Illumination
10 Green/White (-) Output For Interior Light Illumination
11 LT. Blue/Green (-) Output Channel 5
12 DK. Blue (-) Output Channel 3 Trunk
13 Green/Black (-) Output Channel 4
14 DK. Blue/Black (-) Output CH 3 Alternate
1 Red/White (+) 12VDC Module Power
2 Orange (-) Starter Inhibit O/P
3 Black Chassis Ground
4 White/Black (+) Positive Output For Siren
5 Red (+) Parking Relay Power
6 White (+) Parking Relay Output
1 Red Neg. Lock 300mA Max.
2 Green Neg. Unlock 300mA Max.
3 Red/Black 2nd Neg. Unlock 300mA Max.
6 Pin Antenna /Receiver Harness Part #1124293
1 Red + 5 VDC
2 Green RX
3 Black Ground
4 Gray Valet Enable Blue
5 Blue LED Cathode Blue
6 Blue TX
